Baylor brand high precision high quality hydraulic plate shears QC12Y-20*6000 manufacturer from China Ma'anhan Baylor CNC Machine Co.Ltd

Baylor brand high precision high quality hydraulic plate shears

Price:	78000.0~79000.0 USD
Payment Terms:	T/T
Place of Origin:	Anhui, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: QC12Y-20*6000

Production Capacity: 100 sets per month

Delivery Date: 30 days after receive depos...

Means of Transport: Ocean

Packing: wooden case

Brand Name: Baylor

Mainly used for tensile, impact load, bending, flanging process etc. Used in automobiles, tractors, rolling stock, shipbuilding, electrical, etc

specifications	Shearing thickness	shearingwidth	Shearing angle	trip number	the rack behind	Main motor	overall dimensions
mm	mm	(°)	min-1	mm	KW	mm
4×2500	4	2500	1°30′	20	20-500	5.5	3110×1500×1450
4×3200	4	3200	1°30′	18	20-500	5.5	3840×1685×1620
4×4000	4	4000	1°30′	15	20-500	5.5	4640×1850×1700
6×2500	6	2500	1°30′	18	20-500	7.5	3130×1530×1600
6×3200	6	3200	1°30′	15	20-500	7.5	3840×1675×1620
6×4000	6	4000	1°30′	14	20-500	7.5	4630×1800×1620
6×5000	6	5000	1°30′	8	20-500	11	5770×2380×2255
6×6000	6	6000	1°30′	7	20-500	11	6810×2530×3250
8×2500	8	2500	1°30′	10	20-500	11	3140×1665×1620
8×3200	8	3200	1°30′	9	20-500	11	3587×1800×1650
8×4000	8	4000	1°30′	8	20-600	11	4667×1910×1650
8×5000	8	5000	1°30′	7	20-600	15	5612×2600×2350
10×2500	10	2500	1°30′	10	20-600	15	3200×1850×1760
10×3200	10	3200	1°30′	10	20-600	15	3900×1900×1760
12×2500	12	2500	2°	9	20-800	18.5	3210×1920×1850
12×3200	12	3200	2°	8	20-800	18.5	3910×2040×1920
12×4000	12	4000	2°	7	20-800	18.5	4725×2000×2040
12×5000	12	5000	2°	8	20-800	22	5750×2260×2240
16×2500	16	2500	2°30′	8	20-800	22	3300×2150×1880
16×3200	16	3200	2°30′	8	20-800	22	4105×2325×2220
16×4000	16	4000	2°30′	7	20-800	22	4905×2385×2250
20×2500	20	2500	2°30′	6	20-800	30	3400×2350×2700
20×3200	20	3200	2°30′	5	20-800	30	4100×2350×2730
20×4000	20	4000	2°30′	5	20-800	30	4900×2350×2760
25×2500	25	2500	3°	5	20-800	37	3480×2410×2750
25×3200	25	3200	3°	5	20-800	37	4180×2410×2690
25×4000	25	4000	3°	5	20-800	37	4985×2410×2690
32×2500	32	2500	3°30′	4	20-800	45	3300×3450×3200
32×3200	32	3200	3°30′	4	20-800	45	4197×3450×3250
40×2500	40	2500	3°30′	3	20-800	55	3300×3770×3600
